Mohit 100

Oil Expeller - Mohit 100

We are offering to our clients Oil Seeds Expeller (Mohit 100 ) which is suitable for crushing all types of oil seeds whether edible or non-edible.

Salient features of oil Expeller – Mohit 100 (6 Bolts)
• Cast iron bodies and gear box.
• Single reduction gear box with helical gears.
• Fabricated chamber of size: 24″ long x 4″ Inner diameter.
• Cake thickness cannot be adjusted on running machine.
• Case hardened / Tempered worm assembly.
• EN-8 Main Worm Shaft and Driving Shaft.
• Superior quality of oil & cake.
• Maintenance is less & easy.

Specifications of oil expeller – Mohit 100
• Power consumption: 3-phase 7. 5 h. P motor – 960 RPM.
• Feeding drum: single stage with & without steam heating arrangement (as required).
• Highest capacity: 100 kgs per hour (capacity differs with material density & quantity of oil in it.)
• Overall machine dimensions ( approx. )
• Length : 2200mm (86″)
• Breadth : 700mm (27″)
• Height : 1430mm (56″)
